These wheel spacers are commonly installed behind the inner dually to provide additional spacing. They are ideal for vehicles with aftermarket wider tires or rear air bags, helping to ensure proper clearance. Wider tires can also cause rubbing on the front wheels and between the dually wheels, and these spacers effectively address those issues.

Older 8x275 vehicles use M20x1.5 lug nuts, while newer models use M22x1.5. We offer wheel spacers in various configurations to suit your needs. You can choose spacers with M20x1.5 mounting lug nuts and studs, M20x1.5 mounting lug nuts with M22x1.5 studs, or M22x1.5 mounting lug nuts and studs.

Any questions, feel free to contact us at (310) 763-1437.

Features

• Designed for front wheels, rear inner wheels, or between dually wheels.
• Compatible with both Alcoa and aftermarket wheels
• Hub and Wheel Centric, ensuring no vibration at high speeds
• Engineered for extreme-duty vehicles, safe for heavy-duty towing
• Proven to support towing capacities of up to 36,000 lbs with our spacers
• Includes all necessary mounting hardware
• Custom Made in Lynwood, California, USA


Specifications

• Bolt Pattern: 8x275 MM
• Hub Bore: 221 MM
• Wheel Bolt Pattern: 8x275 MM
• Wheel Bore: 221 MM
• Thread Pitch: 20x1.5 | 22x1.5
• Thickness: 2" Most Popular, Other Sizes Available
• Wheel Lip Height: 0.50"(Front & Between Dual) | 1.5" (Behind Rear Inner Wheel)
• Material: Billet Aluminum 6061 T-6
• Hardware: 10.9 Grade
• Finish: Raw Aluminum
• Torque Specs: Factory specifications recommended

Vehicle Compatibility

Wheels being installed must have a 8x275 MM bolt pattern.

Compatible Models
