Venum Wheel

8x200 MM To 8x210 MM Wheel Adapters Hub Centric Billet Conversion

$210.00
Shipping calculated at checkout.
VW-HCA-8200/821015141-141/1541-FRT
Hub Bore
Wheel Bore
Kit

Pickup available at Venum Wheel

Usually ready in 5+ days

8x200 MM To 8x210 MM Wheel Adapters Hub Centric Billet Conversion

** This Product Is Made To Order, May Take Up To 5 Business Days To Ship **

Made Out of USA Grade 6061 T-6 Aluminum Billet Bars.

Fully Hub Centric.

Installation Hardware Included.

Looking For A Custom Size Or Thickness? Give Us A Call ( 310 ) 763-1437

FEATURES

  • These 8x200 MM To 8x210 MM Wheel Adapters Will Work With Dually Wheels
  • Hub/Wheel Centric: Will Not Vibrate At High Speeds
  • Improve Vehicles Handling Characteristics
  • Improve Incorrect Wheel Offsets
  • Enhance Vehicle Appearance; Aggressive Stance
  • Made Out of 6061 T-6 Aluminum Billet Bars
  • Specifically Design For Extreme Duty Vehicles, Towing Safe
  • Mounting Hardware Included
  • Limited Lifetime Warranty

SPECIFICATIONS

  • Vehicle Bolt Pattern: 8x200 MM
  • Vehicle Hub Bore: 142 MM
  • Wheel Bolt Pattern: 8x210 MM
  • Wheel Bore: 154.1 MM
  • Thread Pitch: 14x1.5
  • Thickness: 1.5" - 4"
  • Material : Billet Aluminum 6061 T-6
  • Hardware: 10.9 Steel
  • Finish: Raw / Black Finish Depends on Material Availability
  • Torque Specs: Factory Specs Recommended
  • Rear Adapters Come With A Longer Lip To Accommodate Both Wheels

VEHICLE COMPATIBILTY

Year Make
Model Thread Pitch
2005-2023 Ford
F-350 Dually
14x1.5
2019-2023 Ram 3500 Dually 14x1.5

FREQUENTLY ASKED QUESTIONS

  • What Is The Maximum Towing Capacity?

The maximum towing capacity we have tested on our adapters is 28,000 lbs. We tested this on a 2020 Ram 3500 which is rated to tow 33,000 lbs. with zero issues.

  • My Stud Got Damaged, Can I Buy Replacement Studs?

If for any reason you need to get replacement studs, we also carry them. Please look at the Lug Nuts & Spacers tab for more info.

INSTALLATION INSTRUCTIONS

  • Minimal Trimming of Your Factory Studs Is Required For Adapters 1.5" & Smaller
  • Detailed Installation Instructions Will Be Uploaded.


    PRODUCT VIDEOS

    • Product Videos Will Be Updated Soon

    LUG NUTS & SPACERS

    Lug Nuts

    Thread Pitch Seat Style Link
    14x1.5
    Multiple
    Multiple Lug Nuts

    Wheel Spacers

    Bolt Pattern Wheel Pattern Hub Bore Link
    -
    -
    - -

    WARRANTY

    • Further Warranty Information Will Be Updated Soon
