No Return VNM Forged Wheels Dually 10x285.75 Custom Made Rims

Made to Order: This product is made to order and may take up to 4 weeks to ship.

Finishes: Polished Milled, Powder Coated Black/Milled, or Solid Powder Coated. Over 500 powders in stock.

These dually wheels work great on stock, leveled, and lifted trucks. If you’re not sure which tires or lift you need, or you have a specific look in mind, feel free to reach out.

Sold As:

• 6 Machined Forged Wheels
• 4 Billet Aluminum Center Caps
• 40 Billet Aluminum Lug Nut Covers
• 4 Billet Aluminum Wheel Adapters
• Custom Mounting Hardware

Features

• 1 Pc Mono Block Wheel Construction
• All 6 Wheels Are Machined
• True Directional Wheels
• Designed & Manufactured in House
• All 6 Wheels Come Notched In The Center
• 90 Degree Valve Stems Included
• Custom Mounting Lug Nuts Included
• Made in Lynwood, California, USA

Wheel Specifications

• Wheel Style: Dually
• Wheel Design: No Return
• Wheel Diameter: 20" - 30"
• Wheel Width: 8.25"
• Wheel Bolt Pattern: 10x285.75 MM (Big Rig)
• Wheel Bore: 220.1 MM
• Hub Centric: Yes
• Finish: Select Above
• Load Rating: 4,500 Lbs
• Material: Forged 6061 Aluminum

Offsets & Backspace

Wheel Adapter Specifications

- Billet 6061 Aluminum

• Vehicle Bolt Pattern: Any (Using Wheel Adapters)
• Vehicle Bore: Any
• Wheel Bolt Pattern: 10x285.75 MM
• Wheel Bore: 220.1 MM
• Adapter Thickness: 1.5"
• Lip Thickness: Front: 0.5" | Rear: 1.5"
• Thread Pitch: M22x1.5
• Torque Specs: Factory Specs Recommended

Vehicle Compatibility
